Stainless Steel Wire Mesh

Stainless Steel Wire Mesh is one kind of wire mesh netting, woven or welded by stainless steel wire.

It is also called woven wire,stainless steel wire cloth, stainless steel mesh screen, stainless mesh, stainless wire mesh, ss wire mesh, micron mesh,.

The feaure of Stainless steel is wear-resisting, heat-resisting, acid-resisting and corrosion resisting.

Many different grades of stainless are used in wire mesh. 201, 304,304L,316,316L are the most common, others are used in specific applications to take advantage of each grade’s unique properties.

Inquire Now
PRODUCT DESCRIPTION

Perfectly suited for a wide array of architectural and functional purposes, stainless steel wire mesh has limitless possibilities. stainless steel wire mesh provides practical functionality while adding aesthetic appeal.

Stainless Steel Woven Wire Mesh is easy to install, easy to maintain and is a cost-effective solution for multiple steel applications.

Stainless Steel Wire Mesh Size and Type:

Material: 201, 302, 304, 304L, 310, 316, 316L, 321, 410, 410L, super duplex stainless steel, duplex stainless steel or customized.

Mesh: 2mesh up to 600mesh(mesh: No.of hole in one inch).

Woven type: plain weave, twill weave, plain dutch weave, twill dutch weave.

plain weave, twill weave, plain dutch weave, twill dutch weave,Stainless Steel Wire Mesh

Stainless Steel Wire Mesh

• T-304 stainless steel is the most widely available of all stainless steels in the wire mesh industry. 304 stainless steel is heat resistance. Often referred to 18-8 due to its Chromium-Nickel chemical composition, T-304 SS is available in both woven and welded constructions. commonly used in the wire mesh and wire cloth industry.

• T-316 stainless steel is recognized as the second most widely available of all stainless steels in the wire mesh industry. T-316 SS has excellent corrosion resistance, and in particular, performs well in its ability to resist pitting and crevice corrosion in warm chloride environments. The inclusion of molybdenum is a major factor for the improved corrosion resistance compared to a T-304 SS counterpart.

• Plain weave stainless steel wire mesh

• Twill weave stainless steel wire mesh

• Stainless steel dutch wire mesh

• Stainless steel reverse dutch wire mesh

• Stainless steel herringbone twill weave wire mesh

• Stainless steel crimped wire mesh

• Stainless steel welded wire mesh

Stainless Steel Wire Mesh

Some of the more popular applications and industries that use stainless steel are listed below:

MiningGas godownMetal fencing
SievingConstructionVentilation grilles
CrushersDrain gratingPharmaceutical
ChemicalMosquito netRoom partitions
QuarryingWall claddingFountain covers
SunscreensSpeaker grillesParticle separation

• Stainless Steel Filter Mesh with its excellent resistance against acid, alkali, heat and corrosion, widely used in filtration of equipment for the auto, plastic rubber, chemical fiber textile.

• Stainless Steel Mesh Screen is strong and versatile enough to be installed into window and door frames in order to resist vandals and keep out insects.

• Stainless Steel Wire Mesh is also used as distributor wire mesh and wire mesh tray.

So the stainless steel wire mesh is also called: stainless mesh, screen mesh, wire screen, steel mesh screen, fine mesh screen.

Stainless Steel Wire Mesh, Plain & Twill Weave Woven Wire Cloth Specifications:

MeshWire Dia.Opening Width% of Open Area
inchmminchmm
1x10.0800 2.0300 0.9200 23.3700 84.6
2X20.0630 1.6000 0.4370 11.1000 76.4
3X30.0540 1.3700 0.2790 7.0900 70.1
4X40.0630 1.6000 0.1870 4.7500 56.0
4X40.0470 1.1900 0.2030 5.1600 65.9
5X50.0410 1.0400 0.1590 4.0400 63.2
6X60.0350 0.8900 0.1320 3.3500 62.7
8X80.0280 0.7100 0.0970 2.4600 60.2
10X100.0250 0.6400 0.0750 1.9100 56.3
10X100.0200 0.5100 0.0800 2.0300 64.0
12X120.0230 0.5840 0.0600 1.5200 51.8
12X120.0200 0.5080 0.0630 1.6000 57.2
14X140.0230 0.5840 0.0480 1.2200 45.2
14X140.0200 0.5080 0.0510 1.3000 51.0
16X160.0180 0.4570 0.0445 1.1300 50.7
18X180.0170 0.4320 0.0386 0.9800 48.3
20X200.0200 0.5080 0.0300 0.7600 36.0
20X200.0160 0.4060 0.0340 0.8600 46.2
24X240.0140 0.3560 0.0277 0.7000 44.2
30X300.0130 0.3300 0.0203 0.5200 37.1
30X300.0120 0.3050 0.0213 0.5400 40.8
30X300.0090 0.2290 0.0243 0.6200 53.1
35X350.0110 0.2790 0.0176 0.4500 37.9
40X400.0100 0.2540 0.0150 0.3800 36.0
50X500.0090 0.2290 0.0110 0.2800 30.3
50X500.0080 0.2030 0.0120 0.3100 36.0
60X600.0075 0.1910 0.0092 0.2300 30.5
60X600.0070 0.1780 0.0097 0.2500 33.9
70X700.0065 0.1650 0.0078 0.2000 29.8
80X800.0065 0.1650 0.0060 0.1500 23.0
80X800.0055 0.1400 0.0070 0.1800 31.4
90X900.0050 0.1270 0.0061 0.1600 30.1
100X1000.0045 0.1140 0.0055 0.1400 30.3
100X1000.0040 0.1020 0.0060 0.1500 36.0
100X1000.0035 0.0890 0.0065 0.1700 42.3
110X1100.0040 0.1016 0.0051 0.1295 30.7
120X1200.0037 0.0940 0.0064 0.1168 30.7
150X1500.0026 0.0660 0.0041 0.1041 37.4
160X1600.0025 0.0635 0.0038 0.0965 36.4
180X1800.0023 0.0584 0.0033 0.0838 34.7
200X2000.0021 0.0533 0.0029 0.0737 33.6
250X2500.0016 0.0406 0.0024 0.0610 36.0
270X2700.0016 0.0406 0.0021 0.0533 32.2
300X3000.0051 0.0381 0.0018 0.0457 29.7
325X3250.0014 0.0356 0.0017 0.0432 30.0
400X4000.0010 0.0254 0.0015 0.3700 36.0
500X5000.0010 0.0254 0.0010 0.0254 25.0
635X6350.0008 0.0203 0.0008 0.0203 25.0

Plain Dutch Weave Weave Woven Wire Cloth Specifications:

MeshWarp Wire (in)Shute Wire (in)abs um RatingNom um Rating
8X200.0140 0.0126 330-350280
12X640.0240 0.0165 270-290200
14X880.0200 0.0130 220-240150
20X1500.0098 0.0070 155-165100
24X1000.0150 0.0100 115-12580
30X1500.0090 0.0070 95-10065
40X2000.0070 0.0055 65-7055
50X2500.0055 0.0045 55-6040
80X4000.0049 0.0028 43-4835

Twill Dutch Weave Woven Wire Cloth Specifications:

MeshWarp Wire (in)Shute Wire (in)abs um RatingNom um Rating
20x2500.0098 0.0079 110-12098
30x3600.0098 0.0060 90-10080
40x5600.0070 0.0040 70-7547
120x4000.0040 0.0025 50-5537
120x1600.0040 0.0025 40-4528
80x7000.0040 0.0030 35-4024
200x6000.0024 0.0018 28-3219
165x8000.0028 0.0020 24-2614
165x14000.0028 0.0016 16-189
200x14000.0028 0.0016 12-145
250x14000.0022 0.0016 11-123
325x23000.0015 0.0010 8-92
400X28000.0010 0.0008 6-71

Stainless Mesh hot specifications ordered by customers:

   ◎ 20 50 100 Micron stainless steel wire mesh for water filter;

   ◎ 120 micron mesh, mesh sale, mesh suppliers;

   ◎ 200 300 400 Mesh stainless steel wire screen printing mesh;

   ◎ AISI SUS304 316 316L, mesh 100 micron, 150 220 micron screen, 300 micron mesh;

   ◎ 100 200 300 400 micron stainless steel mesh, 90 100 120 micron screen, 120 micron mesh;

   ◎ 1 3 5 10 20 50 65 100 Micron stainless steel filter sieve woven wire mesh;

   ◎ SS 304 300 micron 50 mesh stainless steel wire mesh 1m X 30m cloth screen;

   ◎ Ultra fine 400 500 600 mesh plain weave stainless steel wire metal mesh;

   ◎ Food grade plain weave 20 40 60 mesh stainless steel 316 316L  wire mesh for filtering;

   ◎ 316 316L 350X40 Mesh stainless steel reversed dutch weave filter wire mesh;

   ◎ Twill weave 450 500 600 635 mesh stainless steel 304 316 wire mesh for filter;

Stainless Steel Mesh Screen Packing:

   ◎ Width of Stainless Mesh: 0.5m to 1.2m and 1.2m-4.0m, special width can produce as customer’s requirement.

   ◎ Length of Stainless Mesh: standard length is 30m per roll, special length can produce as customer’s requirement.

   ◎ Package of Stainless Mesh: waterproof papaer/plastic bag/carton.

Package of Stainless Steel Mesh Screen

As professional Stainless Steel Wire Mesh Supplier and Stainless Steel Wire Mesh Manufacturer, we will supply high quality Stainless Wire Mesh with low price, welcome contact us freely !
